SWIT BM-215-NDI | 21.5" 4K-NDI QLED HDR 100%DCI-P3 Zero-Delay professional FHD Monitor with Auto-Cal
2'579.00 CHF2'787.90 CHF incluso.8.1% IVA
Articolo n.
719.BM-215-NDI
Articolo n.
24 Monate
Disponibilità
non disponibile (Lieferbar in 5-10 Tagen)
21.5-inch Professioneller NDI® Monitor
- 21,5 Zoll 1920×1080 QLED-Panel
- 100% DCI-P3-Farbraumabdeckung
- Augenschonendes VICO 1.97-Panel der A-Klasse
- 4K NDI® Überwachung mit hoher Bandbreite
- 3GSDI 2-in-1-Schleife, HDMI2.0-Eingang
- NDI®-Dekodierung zum 3GSDI-Ausgang
- NDI®/SDI/HDMI PBP- oder PIP-Ansicht
- Automatische Erkennung und Schnellauswahl von NDI®-Quellen
- Unterstützung von NDI® Discover Server
- Unterstützung des NDI® Low-Bandwidth-Modus
- Rec 709 / DCI-P3 / Rec 2020 Farbraumauswahl
- 3DLUT Auto-Selbstkalibrierung ohne PC
- Eingebaute Delog LUTs und Benutzer-LUTs, die über USB hochgeladen werden können
- Wellenform / Vektor / Histogramm
- Schärfehilfe / Falschfarben / Zebra
- 16-Kanal-Audiometer / Lissajous-Muster
- IP-Webserver-Fernsteuerung (zukünftiges Update)
- AC-, DC- und Batterieplatten-Stromversorgung
NDI®, SDI and HDMI
BM-215-NDI monitor provides multiple inputs including:
- High bandwidth NDI® up to 4K;
- 3GSDI input×2; Loop out×1
- NDI® decode to 3GSDI out ×1
- HDMI 2.0 input ×1
NDI® is a registered trademark of Vizrt Group.
LCD Performance
|
Size |
21.5 inches |
|
Display area |
495.6×292.2mm |
|
Resolution |
1920×1080 |
|
Aspect ratio |
16:9 |
|
Brightness |
400nits |
|
Contrast |
3000:1 |
|
Color Gamut |
100% DCI-P3 |
|
Color depth |
10bit (8+2FRC) |
|
Eye Protect |
VICO 1.97 |
|
Viewing angle |
178°(H) /178°(V) |
Input
|
RJ45 ×1 |
High bandwidth 4K NDI® |
|
BNC ×2 |
3G/HD/SD-SDI input |
|
HDMI ×1 |
HDMI 2.0 input |
|
RS485 ×1 |
TSL 3.1/4.0 UMD input |
|
RS485 ×1 |
GPI (Tally) input |
Output
|
BNC ×1 |
3G/HD/SD-SDI loop output |
|
BNC×1 |
NDI® decoded to SDI output |
|
RS485 ×1 |
TSL 3.1/4.0 UMD output |
|
Analog audio |
3.5mm headphone and speaker |
Video Format
|
NDI® |
4096×2160p (30 / 29.97 / 25 / 24 / 23.98) |
| 3840×2160p (30 / 29.97 / 25 / 24 / 23.98) | |
| 2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
| 2048×1080i (50 / 59.94 / 60) | |
| 1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
| 1080i (60 / 59.94 / 50) | |
| 720p (60 / 59.94 / 50) | |
|
NDI® decoded to SDI out |
2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) |
| 2048×1080i (50 / 59.94 / 60) | |
| 1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
| 1080i (60 / 59.94 / 50) | |
| 720p (60 / 59.94 / 50) | |
|
SDI IN1/2 and LOOP |
2048×1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) |
| 2048×1080i (50 / 59.94 / 60) | |
| 1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
| 1080i (60 / 59.94 / 50) | |
| 1080psf (30 / 29.97 / 25 / 24 / 23.98) | |
| 720p (60 / 59.94 / 50) | |
| 480i (59.94), 576i (50) | |
|
HDMI IN |
4096×2160p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) |
| 3840×2160p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
| 1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) | |
| 1080i (60 / 59.94 / 50) | |
| 720p (60 / 59.94 / 50) |
General
|
Input voltage |
DC 12V-17V, AC 100-240V, 50/60Hz |
|
Power consumption |
45W |
|
Working temperature |
0°C～+50°C |
|
Working humidity |
10%～90% |
|
Storage temperature |
-15°C～+60°C |
|
Storage humidity |
10%～90% |
|
Dimensions |
530.6×364.3×74.2mm |
|
Net weight (main body) |
Net 5.90kg; With package 10.05kg |
Raccomandiamo adeguatamente o come alternativa
non disponibile (Verfügbarkeit unbekannt)
Arri Cable CAM (10p) - Red WEAPON (0.5m/1.6ft)
