Indie 7 RED® RCP2™ Kit (KOMODO®, DSMC3
1'899.00 CHF2'052.80 CHF incl.8.1% VAT
Item no.
161.16-0712-R2
Item no.
12 months
Availability
Not available (Lieferbar in 2-3 Wochen)
This kit includes everything you need to control your RED® KOMODO® or RED® V-RAPTOR™ (DSMC3™) camera with the Indie 7Featuring hyper-responsive touchscreen technology, backed. by 1000nits of brightness for daylight visibility.Unlock access to camera control for RED® KOMODO® and DSMC3™ cameras with the included software license (QR Code Card) and tap into the internal camera settings with intuitive touchscreen configuration tools. Includes RED® EXT 9-pin to SmallHD 5-pin USB Camera-Control Cable (18in/45cm) and Micro USB to 5-pin Lemo Adapter for full tethering and camera accessibility. *Camera and SDI Cable are not included.
Special Note: If you already own Komodo Control, unlock the expanded RCP2 Control by downloading the latest firmware for your monitor at https://downloads.smallhd.com.
Camera Control for RED® KOMODO™
Access all camera features available thru RED Camera Protocol (RCP2)
PageOS 4 Software Toolset
User page presets, Focus Assist, frame guides, 4K HDR (PQ) waveforms, improved false color, Color Pipe log conversion, etc. Monitor camera metadata, timecode, and start/stop flags. Learn more about PagesOS 4
Responsive Touchscreen with Daylight Visibility
Full HD 7-inch IPS LCD with 1920x1200 resolution
10-bit color processing in 100% Rec 709
1000nits of brightness
4K & HDR compatible
160-degree viewing angle
Versatile I/O
Input: 1x 3G-SDI, 1x 3G-SDI In/Out, 1x HDMI 2.0, 1x Micro USB
Output: 1x 3G-SDI, 1x HDMI 2.0
Anodized aluminum chassis
Featherlight weight: 1.1lbs (.53kg)
Ultrathin body width: 1.2in (3.35cm)
Special Note: If you already own Komodo Control, unlock the expanded RCP2 Control by downloading the latest firmware for your monitor at https://downloads.smallhd.com.
Camera Control for RED® KOMODO™
Access all camera features available thru RED Camera Protocol (RCP2)
PageOS 4 Software Toolset
User page presets, Focus Assist, frame guides, 4K HDR (PQ) waveforms, improved false color, Color Pipe log conversion, etc. Monitor camera metadata, timecode, and start/stop flags. Learn more about PagesOS 4
Responsive Touchscreen with Daylight Visibility
Full HD 7-inch IPS LCD with 1920x1200 resolution
10-bit color processing in 100% Rec 709
1000nits of brightness
4K & HDR compatible
160-degree viewing angle
Versatile I/O
Input: 1x 3G-SDI, 1x 3G-SDI In/Out, 1x HDMI 2.0, 1x Micro USB
Output: 1x 3G-SDI, 1x HDMI 2.0
Power Input Options
2mm barrel connector port
Included Sony L-Series dual battery bracket
Optional Gold Mount & V-Mount battery plate attachments (sold separately)
Anodized aluminum chassis
Featherlight weight: 1.1lbs (.53kg)
Ultrathin body width: 1.2in (3.35cm)
SKU
SKU
16-0712-R2
Product ID
Product ID
6631136395397
Environmental
Item Weight (oz)
18.9
Package Weight (oz)
26
Height (in)
4.67
Width (in)
1.32
Length/Depth (in)
7.09
Compliance
FCC, IC, CE, RoHS
Operating Temperature
30F to 100F
Storage Temperature
0F to 120F
Mount Points
Four ¼-20 Mount Points (Left, Right, Bottom, and Back)
Construction
Anodized aluminum chassis
Display
Panel Type
IPS LCD Touchscreen
Diagonal Size
7.02
Resolution
1920x1200
Pixel Density
323
Aspect Ratio
16:9
Active Area
5.95 x 3.72
Brightness
1000 Nits
Contrast
1000:1
Gamut
100% rec709
Color Depth
10-bit Processing (8-bit panel)
Viewing Angle
160
Backlight Type
LED
Adjustable Backlight
Yes
Brightness
1000 Nits
DCI-P3 Color
100% rec709
Input Signal
3G-SDI Input Types
YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
HD-SDI Input Types
YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
SD-SDI Input Types
YCC 4:2:2 @ 10-bits: 480i59.94, 576i50
HDMI Input Types
YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 3840x2160 30p, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i50
Audio Input Types
HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels
Output Signal
3G-SDI Output Types
YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i100
HD-SDI Output Types
YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98
SD-SDI Output Types
YCC 4:2:2 @ 10-bits: 480i59.94, 576i50
HDMI Output Types
YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4: 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200
Audio Output Types
HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection
Connector Type
SDI
1x BNC 3G input and 1x BNC 3G selectable input/output
HDMI
1 input and 1 output: HDMI Type-D Receptacles (full size)
Audio
1x 3.5mm 3-pin Stereo Headphone Jack
Power In
Barrel, 2.0mm ID, 5.5mm OD (center pin positive)
USB
1x USB 2.0 Micro-B receptacle
Controls
Primary
Touch Screen
Record Capture
Image Capture Tool
Power
Connector
Barrel, 2.0mm ID, 5.5mm OD (center pin positive)
Voltage
DC in - 10V minimum to 34V maximum, Battery terminals - 6.0V minimum to 16.8V max
Consumption
17.3 watts (2160p30, 100% bright, tools enabled), (2.4A @7.2V battery, 1.4A @12V barrel, 0.7A at 24V barrel)
Battery Plate Included
L-Series standard (V Mount or Gold Mount optional accessories)
Power Supply
Recommend DC 12~15V at ~2.5 amp or greater
Battery Types
L-Series, V Mount, Gold Mount
Overload Protection
DC input: Reverse polarity
Battery Chemistry
Li-ion
Battery Charging Time
Monitor does not support the charging of batteries
Power Plug-in
Barrel Connector
Software
Pixel Zoom
1.1-2.0x & 2.0-8.0x via swipe up/down. Infinitely adjustable via pinch & zoom
Frame Guides
Preset Aspect Ratios & Customizable
DSLR Scale
Canon 5DMkii & Canon 7D
Custom Scale
Yes (Underscan Only)
Anamorphic De-Squeeze
0.75x, 1.33x, 1.5x, 1.66x, 2.0x, 2.5x
Image Rotate
Automatic or Manual Control
Image Flip
Automatic or Manual Control
Cross Conversion
Yes: HDMI → SDI & SDI → HDMI
Focus Assist
User Adjustable Color Style and Intensity
Peaking
User Adjustable Intensity
False Color
Rainbow, Arri Style, Custom with up to 10 nodes
Zebra
Dual - User Configurable
Waveform
Luma & RGB Style, Fully User Customizable w/ Region of Interest Highlighting
Vectorscope
Yes
RGB Parade
Fully User Customizable
Histogram
Luma & RGB Style
Image Capture
Yes
Custom LUTS
Loadable as Looks on Pages or as Systemwide Color Calibration via the settings menu
LUT Downstream
Available on SDI or HDMI Out. Applied on Output Preview Page.
LUT Import
via SD Card or USB Storage Device
Overlay
With Opacity Slider and Blink Setting
Audio Meters
HDMI & SDI up to 8 channel
Notes
Access all camera features available thru RED Camera Protocol (DSMC2 interface only)
Camera Control
Camera Control Compatibility
RED® KOMODO™ RED DSMC2®
