Cine 13
Cine 13Cine 13Cine 13Cine 13

Cine 13

4'499.00 CHF
4'863.40 CHF incl.8.1% VAT
Item no.
161.MON-CINE-13
Item no.
12 months
Availability
Not available (Verfügbarkeit unbekannt)

Cine 13" 4K High-Bright Monitor


Bildschirm: 13" 3840 x 2160
Hintergrundbeleuchtung Typ: LCD
Anzeige: 13-Zoll, 3840 x 2160, 1500nits
SDI: 4x 12G-SDI-Eingang, 4x 12G-SDI-Ausgang
HDMI: 1x HDMI 2.0-Eingang, 1x HDMI 2.0-Ausgang
Stromeingang: 1x 4-pin XLR


Der Cine 13 ist der bisher agilste, hellste und pixelstärkste 4K-Produktionsmonitor von SmallHD. Mit einer Helligkeit von über 1500nits und einer Auflösung von 3840 x 2160 ist 4K jetzt mobiler denn je. Dank seines flachen Designs kann dieser Feldbegleiter für nahezu jede Situation aufgerüstet werden. Mit brillanter Tageslichtsicht und voller 4K-Klarheit ist der Cine 13 für Kreative am Set gedacht, die eine kritische Fokussierungsfunktion und ein großes Display benötigen.



Highlights der Plattform


Software-Plattform PageOS 4
4K HDR-Wellenformen und -Scopes
Dual- und Quad-Ansicht*
Color Pipe Farbwiedergabe
Assistent für die Monitorkalibrierung
Small4K™-Videoverarbeitungsarchitektur
Eingänge: 4x 12G-SDI, 1x HDMI 2.0
Ausgänge: 4 x 12G-SDI, 1 x HDMI 2.0*
Unibody Smart-Gehäuse
Arca Slide-On Rail für die Montage von Batterien und Zubehör
2x 2-polige Stromausgänge für Zubehör
Inklusive unterer Montageschiene für ultimative Flexibilität
Stromversorgung
1x 4-poliger XLR-Anschluss
Hot-Swap-fähige Dual-Eingänge
Dual-GM/VM-Batterieplatte (separat erhältlich)



Im Lieferumfang enthalten

4K-HDMI-auf-4K-HDMI-Kabel (120 Zoll/305 cm)
SmallHD 4K Monitorfüße (Satz)
8GB SD-Karte
SmallHD Reinigungstuch
Basic Acrylic Locking Displayschutzfolie für Cine 13
Netzgerät für Cine 13



Spezifikationen

Environmental

Item Weight (oz)

108.8

Display

Diagonal Size

13.3

Resolution

3840x2160

Brightness

1500nits

Contrast

1300:1

Gamut

100% REC.709

Color Depth

10-bit (8+2)

Backlight Type

Edgelit

Display Size

13"

Panel Resolution

3840 x 2160

Brightness

1500nits

Color Bit Depth

10-bit (8+2)

Backlight Type

Edge-Lit

DCI-P3 Color

100% REC.709

EVF

Height (in)

10.1 (w/out feet and handle) 12.4 (w/ feet and handle)

Width (in)

13.2 (w/out feet and handle) 13.2 (w/ feet and handle)

Depth (in)

2.3 (w/out feet and handle) 4.7 (w/ feet and handle)

Weight

6.8lbs/3.09kg

Input Signal

12G-SDI Input Types

4x 12G-SDI

HDMI Input Types

1x HDMI 2.0 (4K60)

Output Signal

12G-SDI Output Types

4x 12G-SDI

HDMI Output Types

Coming Soon

Audio Output Types

1x 3.5mm 3-pin Stereo Headphone Jack(coming soon)

Data I/O

Connector Type

1x SD Card Slot, 1x RJ45 Ethernet, 1x RJ45 GPI

Power

Input

1x XLR 4-pin 12 - 34VDC IN (210W max, 12V-34V, 18A max)

Output

2x 2pin (12V / 2A combined) 1x USB (2.4A) (Front) 1x USB (1.5A) (Front) 1x USB-C (5V / 1.5A)

Consumption

36.7w (monitor only) 117.9w (w/max access. power draw)

Battery Plate Included

No

Battery Types

1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)
